High Gain New Design Ku Band Twin LNB
High gain new design ku band twin lnb Futures:1. Full coverage of Ku-Band for Analog and HD Digital reception2. Low noise figure3. Easy installation4. Low power consumption5. High quality weather protectionSPECIFICATIONS: ItemSpecificationItemSpecificationInput Frequency RangeLow Band:10.70~11.70GH......
Send Inquiry
Product Description
High gain new design ku band twin lnb
FAQ:
Q1:Are you a trading company or manufacturer?
We are professional manufacturer for audio&video cable . also we supply of different electrical and electronic items
Q2: why will you choice us :
more than 15 years of professional teams will give you good quality products ,good service ,and reasonable price .
Q3:Can we have our logo or company name to be printed on your products or the package?
We offer OEM , ODM . our designer can make special design for you .
Q4: Is the MOQ fixed?
The MOQ is flexible and we accept small order as trial order.
Q5:Can I have a visit to you before the order?
Sure,welcome to visit our company ..
our company is only one hour by train from shanghai
Futures:
1. Full coverage of Ku-Band for Analog and HD Digital reception
2. Low noise figure
3. Easy installation
4. Low power consumption
5. High quality weather protection
SPECIFICATIONS:
| Item | Specification | Item | Specification |
| Input Frequency Range | Low Band:10.70~11.70GHz | Gain Flatness | ±0.5dB/26MHz |
| High Band:11.70~12.75GHz | Cross POL. Isolation | 25dB(Typ.) | |
| Output Frequency Range | Low Band:950~1950MHz | Image Rejection | 40dB(Min.) |
| High Band:1100~2150MHz | Output VSWR | 2.0:1(Max.) | |
| L.O. Frequency | Low Band:9.75GHz | P1dB | 0dBm (Min.) |
| High Band:10.60GHz | DC Current Consumption | 80mA(Typ.) | |
| L.O. Frequency Stability | ±1.0MHz (Max.)@+25ºC | Low/High Band Switching | Low Band:0Hz |
| ±2.0 MHz (Max.)@-30ºC~+70ºC | High Band:22KHz±4KHz | ||
| L.O. Phase Noise | -60dBc/Hz@1KHz | POL. Switching Voltage | 10.5~14.0V @Vertical |
| -80dBc/Hz@10KHz | 16.0~20.0V @Horizontal | ||
| -100dBc/Hz@100KHz | Relative Humidity | 0%~95% | |
| Conversion Gain | 60dB(Typ.) | Operating Temperature | -30ºC~+70ºC |
| Noise Figure | 0.6dB(Typ.) | Connector Type | 75Ω Female Connector |
FAQ:
Q1:Are you a trading company or manufacturer?
We are professional manufacturer for audio&video cable . also we supply of different electrical and electronic items
Q2: why will you choice us :
more than 15 years of professional teams will give you good quality products ,good service ,and reasonable price .
Q3:Can we have our logo or company name to be printed on your products or the package?
We offer OEM , ODM . our designer can make special design for you .
Q4: Is the MOQ fixed?
The MOQ is flexible and we accept small order as trial order.
Q5:Can I have a visit to you before the order?
Sure,welcome to visit our company ..
our company is only one hour by train from shanghai
