Outdoor Dome Gjs98-008/98-009/99/97 Heat Shrinkable Sealing Fiber Optic Cable Splice Closure

Product Description

Outdoor Dome GJS98-008/98-009/99/97 Heat Shrinkable Sealing Fiber Optic Cable Splice Closure

Model	Dimensionmm (L*D)	Material	Sealing Structure	Cable Capacity(port)	Max Capacity (core)
GJS98-008	455*240	PC	Heat Shrinkable Seal	Three Into Three Out	144(core)Bundle/ 288(core)Tape
GJS98-009	455*240	PC	Heat Shrinkable Seal	Three Into Three Out	144(core)Bundle/ 288(core)Tape
GJS99	455*240	PC	Heat Shrinkable Seal	Three Into Three Out	144(core)Bundle/ 288(core)Tape
GJS97	420*210	pc	Heat Shrinkable Seal	Three Into Three Out	144(core)Bundle/ 288(core)Tape

GJS98-008/GJS98-009/GJS99/GJS97 dome type cable splice closure with sleeve structure, the use of the lever and the principle of self-locking box through the hoop and seal fixed seal, the use of heat shrink tubing seal.
♦ Suitable for various occasions such as overhead, piping, burial and so on
♦ The box is tightened with a hoop and easy to install
♦ The splice tray can be rotated more than 90 degrees, the storage space is large, the operation is simple and the expansion is convenient
♦ Suitable for bundled cable and integrated beam cable

GJS98-008

GJS98-009

GJS99

GJS97
