Guangtai Optical Fiber Dcm Dispersion Compensation Module Dcm -G. 655-C-Fxx
Product DescriptionDCM-G.655-C-Fxx dispersion compensation fiber module is designed for single mode optical fiber G.655 C band, dispersion and dispersion slope compensation for wide band, the system optimized residual dispersion. The PCVD module based on optical fiber technology is mature and reliab......
Send Inquiry
Product Description
1. DWDM system wide band dispersion compensation and low participation dispersion channel
2. G.655 100% C band dispersion compensation fiber
3. Dispersion compensation value range is 10~200Km optional.
4. Low insertion loss
5. Low polarization mode dispersion
6. Excellent performance price ratio
1. Big effective area of G.655 optical fiber long and Metro Communication System
2. DWDM transmission system
3. CATV cable TV system
4. Dispersion adjustment
| Performance | Index | Supplement | ||||
| Min. | Typ. | Max. | ||||
| Working wavelength | (nm) | 1525 | 1565 | |||
| Compensated optical fiber length | (Km) | 10 | F10 | |||
| 20 | F20 | |||||
| 40 | F40 | |||||
| 60 | F60 | |||||
| 80 | F80 | |||||
| 100 | F100 | |||||
| 120 | F120 | |||||
| 160 | F160 | |||||
| 200 | F200 | |||||
| Dispersion Value (1545nm) | (ps/nm) | -33 | 37 | 41 | F10 | |
| -69 | 75 | 81 | F20 | |||
| -138 | 150 | 162 | F40 | |||
| -202 | 220 | 242 | F60 | |||
| -280 | 300 | 320 | F80 | |||
| -350 | 370 | 390 | F100 | |||
| -420 | 450 | 480 | F120 | |||
| -560 | 600 | 640 | F160 | |||
| -700 | 750 | 800 | F200 | |||
| Insert Ioss | (dB) | 4.7 | F10 | |||
| 4.7 | F20 | |||||
| 4.7 | F40 | |||||
| 5.5 | F60 | |||||
| 5.9 | F80 | |||||
| 6.5 | F100 | |||||
| 7.1 | F120 | |||||
| 8.3 | F160 | |||||
| 9.5 | F200 | |||||
| Polarized Mode Dispersion (PMD) | (dB) | 0.4 | 0.5 | F10 | ||
| 0.4 | 0.5 | F20 | ||||
| 0.4 | 0.5 | F40 | ||||
| 0.5 | 0.6 | F60 | ||||
| 0.6 | 0.7 | F80 | ||||
| 0.7 | 0.8 | F100 | ||||
| 0.8 | 0.9 | F120 | ||||
| 0.9 | 1.0 | F160 | ||||
| 1.0 | 1.1 | F200 | ||||
| RSD | (nm-1) | 0.022+/-20% | ||||
| Optical fiber connector | LC/UPC,SC/ACP,MU/UPC | |||||
| Return Loss | (dB) | -45 | ||||
| Operating Temp. | ( ºC ) | -5 | +70 | |||
| Store Temp. | ( ºC ) | -40 | +85 | |||
| Size (W)×(D)×(H) | ( " ) | 19×11×1.75 | ||||
1. What are the payment terms of payment?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is more convenient for you.
2. What about the lead time?
Usually, if there's stock, we ship the goods within 5-7 working days after the deposit is confirmed. If it is out of stock, the lead time depends.
3. How about the shipping?
When the package is small, we will deliver the goods via international Express like FedEx , DHL,TNT and UPS and so on. Door to door delivery service will be provided; while the goods have high weight and volume, we suggest using air or sea shipment.
4. Can you do OEM for us?
Yes. if there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.
5. What are the advantages of your products?
A. Good quality and competitive prices
B. Strict quality control during production process.
C. Professional operations in processes of production, sales, assembling, packaging and shipping
D. Good after-sale service. Professional online technical support can be provided. Moreover, if there is any problem of the goods, we will help to solve the problem or provide replacement of the goods
6. How about the Warranty?
There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.
