Guangtai 2X1 Optical RF Switch Hrs-201
Product DescriptionHRS-201 2×1 RF switch, with its high resolution to the RF monitor, it could be widely applied in the system which need to control, switch or redundancy the RF signalProduct Features1. High resolution of RF monitor2. Standard RS232 communication interface3. Integrate SNMP......
Send Inquiry
Product Description
1. High resolution of RF monitor
2. Standard RS232 communication interface
3. Integrate SNMP network management function.
4. The switch mode is automatic or manual.
5. Switch reference level can be set through front panel or Internet.
1. CATV RF switching, redundancy backups.
2. RF control system.
3. Laboratory.
| Performance | Index | Supplement | ||
| Optic feature | Operating bandwidth | (MHz) | 5~1000 | |
| Input level range | (dBμV) | 50~130 | ||
| Control level range | (dBμV) | 60~120 | ||
| Resolving capability | (dB) | ≤0.5 | ||
| Switch mode | AGC & MGC | |||
| Switch time | (ms) | ≤10 | ||
| Insertion loss | (dB) | 1.2~2.2 | ||
| Flatness | (dB) | ≤0.5 | ||
| Return loss | (dB) | ≥16 | 5~1000MHz | |
| Impedance | 75 | |||
| RF connector | F-female | |||
| General feature | Communication interface | RS232 | ||
| SNMP Network management interface | RJ45 | |||
| Power supply | (V) | 95~250VAC | Optional -48VDC(30~60VDC) | |
| Power consume | (W) | 10 | ||
| Operating temp. | (ºC) | 5~65 | ||
| Storage temp. | (ºC) | -40~85 | ||
| Relative humidity | (%) | 5~95 | ||
| Size (W)×(D)×(H) | ( " ) | 19×10.5×1.75 | ||
