Product Description

1310nm RF Transmitter FWT-1310T-26mW (14dB)

Fullwell RF Transmitter for 1310nm Wavelength Max 14dB

Serial No.	Project	Unit	Parameter	Remark
1	Laser model		DFB
2	Optical wavelength	nm	1310±10	if it is from the wavelength, please marking before order
3	Optical modulation modes		Intensity modulation
4	Optical output power	mW	14	4~26
5	Optical connector form		SC/APC optionally	Please marking before order
6	Frequency range	MHz	45~750(862)
7	Carrier to Noise ratio	dB	≥52.0	According to GY/T143-2000 6.2.3.5
8	Flatness	dB	±0.75	According to GY/T143-2000 6.2.4
9	RF input signal level	dBuV	75~85	AGC automatic control
10	C/CTB	dB	≥65.0	According to GY/T143-2000 6.2.5
11	C/CSO	dB	≥65.0	According to GY/T143-2000 6.2.5
12	RF input impedance	Ω	75
13	RF input reflection loss	dB	>16(47~550)MHz	According to GB/T11381.1
13	RF input reflection loss	dB	>14[550~750(862)MHz	4.2.2.2.5
14	Power supply	V	90~265 mains
15	power consumption	W	≤50	Single power source
16	Power source
17	Operating temperature	ºC	0~50	Automatic chassis controls the temperature
18	Storage temperature	ºC	,-20~85
19	Working relative humidity	%	20%~85%
20	Size	″	19″×11″×1.75″	(W)x(D)x(H)
21	Network management interface		RJ45	Support browser and SNMP

More information
FAQ:
Q1: Are you a factory or trading company?
A: We're a professional trading company with excellent cooperative factories.

Q2: Where is your company located?
A: Our company is located in Hangzhou City, Zhejiang Province, China. All our clients, from home or abroad
are warmly welcomed to visit us!

Q3: Do your products safe enough?
A: Our products meet with the certificate of CE, ISO & Rosh. Our products are made according to the
standard of the market in our clients. They're all in superior quality & competitive price. You can rest
assure that they are safe enough.

Q4: How long does your warranty provide?
A: We usually provide you a 2-year warranty after the date we sold under normal usage.

Q5:What are your payment terms?
A: T/T, Western Union, Money Gram

Q6:What's your delivery time?
A: Around 8 working days after getting payment in the account ( or pre-payment)

Q7:Can you accept OEM?
A: Yes. We would accept OEM&ODM.

"Design and manufacture the most reliable and efficient FTTH CATV equipment products in the industry."

If this model meets your interest, please let us have your specific inquiry, our quotation will be forwarded timely!
