Fiber Optic 20km 1.25G 1310/1550nm Fiber Transceiver SFP 1.25G LR Module
WAREX's WXP-CXX192-EL40D is a very compact 10Gb/s optical transceiver module for serial optical communication applications at 10Gb/s.The WXP-CXX192-EL40D converts a 10Gb/s serial electrical data stream to 10Gb/s optical output signal and a 10Gb/s optical input signal to 10Gb/s serial electrical data streams.The high speed 10Gb/s electrical interface is fully compliant with SFI specification.The high performance 1470~1610nm CWDM EML transmitter and high sensitivity PIN receiver provide superior performance for Ethernet applications at up to 40km links.
APPLICATIONS
· 10GBASE-ER/EW 10G Ethernet
· 40km 10G Fibre Channel
· SONET OC-192 IR-2/3,SDH STM S-64.2/3b,ITU-T G.709
· Other optical link
FEATURE
· Supports 9.95 to 11.3Gb/s bit rates
· Hot-pluggable XFP footprint
· Cooled 1550nm EML laser ,PIN photo-detector
· Applicable for 40km SMF connection
· Low power consumption, <2.0W
· Digital Diagnostic Monitor Interface
· Operating case temperature: Commerical:0 to 70 °C,Industrial:-40 to 85°C
SPECIFICATION OF SFP SR/LR/ER/ZR
Aboslut Maximum Ratings
| Parameter | Symbol | Min. | Typical | Max. | Unit |
| Storage Temperature | TS | -40 | +85 | °C | |
| Case Operating Temperature | TA | 0 | 70 | °C | |
| Maximum Supply Voltage | Vcc | -0.5 | 4 | V | |
| Relative Humidity | RH | 0 | 85 | % |
Electrical Characteristics (TOP = 0 to 70 °C, VCC = 3.135 to 3.465 Volts)
| Parameter | Symbol | Min. | Typical | Max. | Unit | Note |
| Supply Voltage | Vcc | 3.135 | 3.465 | V | ||
| Supply Current | Icc | 500 | mA | |||
| Power Consumption | P | 1.8 | W | |||
| Transmitter Section: | ||||||
| Input differential impedance | Rin | 100 | Ω | 1 | ||
| Tx Input Single Ended DC Voltage Tolerance (Ref VeeT) | V | -0.3 | 4 | V | ||
| Differential input voltage swing | Vin,pp | 180 | 700 | mV | 2 | |
| Transmit Disable Voltage | VD | 2 | Vcc | V | 3 | |
| Transmit Enable Voltage | VEN | Vee | Vee+0.8 | V | ||
| Receiver Section: | ||||||
| Single Ended Output Voltage Tolerance | V | -0.3 | 4 | V | ||
| Rx Output Diff Voltage | Vo | 300 | 850 | mV | ||
| Rx Output Rise and Fall Time | Tr/Tf | 30 | ps | 4 | ||
| LOS Fault | VLOS fault | 2 | VccHOST | V | 5 | |
| LOS Normal | VLOS norm | Vee | Vee+0.8 | V | 5 | |
Optical Parameters(TOP = 0 to 70°C, VCC = 3.135 to 3.465 Volts)
| Parameter | Symbol | Min. | Typical | Max. | Unit | Note |
| Transmitter Section: | ||||||
| Center Wavelength | λc | λ-6.5 | λ+6.5 | nm | ||
| spectral width | △λ | 1 | nm | |||
| Average Optical Power | Pavg | -1 | +4 | dBm | 1 | |
| Laser Off Power | Poff | -30 | dBm | |||
| Extinction Ratio | ER | 8.2 | dB | |||
| Transmitter Dispersion Penalty | TDP | 3.2 | dB | 2 | ||
| Relative Intensity Noise | Rin | -128 | dB/Hz | 3 | ||
| Optical Return Loss Tolerance | 20 | dB | ||||
| Receiver Section: | ||||||
| Center Wavelength | λr | 1260 | 1620 | nm | ||
| Receiver Sensitivity (OMA) | Sen | -16 | dBm | 4 | ||
| Stressed Sensitivity (OMA) | SenST | -14 | dBm | 4 | ||
| Los Assert | LOSA | -27 | - | dBm | ||
| Los Dessert | LOSD | -17 | dBm | |||
| Los Hysteresis | LOSH | 0.5 | dB | |||
| Overload | Sat | 0 | dBm | 5 | ||
| Receiver Reflectance | Rrx | -12 | dB | |||
