Product Description

Description:
Lightwit's rack-mounted 48-channel DWDM multiplexer (Mux) and demultiplexer (DeMux) module provide excellent solution for infrastructure savings by aggregating 48 different wavelengths on a single fiber. These products are protocol transparent. All 48 channels are in the C-band with distance of 100 GHz between channels with high quality AWG flat technology.

48CH C17-C64 100g Athermal AWG 48CH 100g Aawg 48CH DWDM Mux/Demux

48CH C17-C64 100g Athermal AWG 48CH 100g Aawg 48CH DWDM Mux/Demux

Features:
High isolation
Low insertion loss
MUX/DEMUX Functionality
Athermal design

Applications:
DWDM Metro and Long-Haul Networks

Fiber savings for data centers connectivity

DWDM Transmission
Building Blocks for ROADM
Building Blocks for VMUX
PON Networks

Specifications:

Parameter	Value
Input Channel	1
Output Channel	40
Channel Spacing (GHz)	100
Reference Passband(GHz)	-12.5/+12.5
Wavelength Accuracy (pm)	-50/+50
1dB Bandwidth (nm)	0.4
3dB Bandwidth (nm)	0.6
Insertion Loss (dB)	6
Insertion Loss Uniformity (dB)	1
Ripple (dB)	0.7
PDL(dB)	0.5
Adjacent Crosstalk (dB)	25
Non-Adjacent Crosstalk (dB)	30
Total Crosstalk (dB)	22
Return Loss (dB)	40
Maximum Continuous Optical Power (mW)	250
Chromatic Dispersion(CD) (ps/nm)	-20/+20
PMD (ps)	0.5

Order information:
AAWG-XXX-X-XX-XXX-XX-XXXX-XX

Channel Spacing	Passband Profile	Channel Number	Start Channel number	Common Length	Ribbon / Fan out length	Connecter
100=100G 050=50G	F=Flat top G=Gaussian	16=16CH 18=18CH ... 40=40CH 48=48CH	C17=C17 C18=C18 ... C21=C21 XX=others (Refer to ITU Channel Table)	05=0.5M 10=1.0M XX=others	0505=0.5M/0.5M 1010=1.0M/1.0M	LU=LCUPC LA=LCAPC FA=FCAPC FU=FCUPC SA=SCAPC SU=SCUPC XX=others
