              OEM Brand 40g Qsfp 850nm Active Fiber Optical Cable with 3 Meters
              • OEM Brand 40g Qsfp 850nm Active Fiber Optical Cable with 3 MetersOEM Brand 40g Qsfp 850nm Active Fiber Optical Cable with 3 Meters

              OEM Brand 40g Qsfp 850nm Active Fiber Optical Cable with 3 Meters

              Ordering InformationPart No.Data RateAOC LengthTemp.DDMIMU-QS40-AXC40Gbps1~100m0ºC~+70ºCYesFeaturesCompliant to the IEEE 802.3ba(40GBASE-SR4)40Gbps aggregated bidirectional data throughputCompliant to the QSFP+ MSA SFF-8436 SpecificationActive Optical Cables Length up to 100mVCSEL ......

              Send Inquiry

              Product Description

              Ordering Information

              Part No.Data RateAOC LengthTemp.DDMI
              MU-QS40-AXC40Gbps1~100m0ºC~+70ºCYes

              Features

              1. Compliant to the IEEE 802.3ba(40GBASE-SR4)
              2. 40Gbps aggregated bidirectional data throughput
              3. Compliant to the QSFP+ MSA SFF-8436 Specification
              4. Active Optical Cables Length up to 100m
              5. VCSEL array transmitter and PIN array receiver
              6. Low Power dissipation <0.35W per channel
              7. Infiniband 4XQDR/40G Base-SR10 Compliant Laser Class 1
              8. Operating Case Temperature: 0ºC~+70ºC
              9. Safety Certification: TUV/UL/FDA
              10. RoHS Compliant

              Applications

              1. InfiniBand QDR (4 x 10G), DDR (4 x 5G) and SDR (4 x2.5G) interconnects
              2. High Performance and High Productivity computer interconnects
              3. Data Aggregation, Backplane and Proprietary Density Applications
              4. PCI-Express, SAS/SATA, Fibre Channel compatible interconnect
              5. Datacom and Telecom switch and router backplane connections

              Optical and Electrical Characteristics

              Absolute Maximum Ratings*

              ParameterSymbolMin.Max.Unit
              Storage TemperatureTs-40+85°C
              Supply VoltageVcc-0.53.6V
              Operating Relative HumidityRH585%
              *Exceeding any one of these values may destroy the device immediately.

              Recommended Operating Conditions

              ParameterSymbolMin.TypicalMax.Unit
              Operating Case TemperatureTcEOLQ-8540G-PCT-XX0 +70°C
              Power Supply VoltageVcc3.153.33.45V
              Aggregate Bit RateBRAVE 41.25 Gbps
              Lane Bit RateBRLANE 10.3125 Gbps
