Product Description

24V 1000W Rectifier Module Eltek Flatpack S 24/1000 HE 241122.205

Eltek 241122.205 Profile

The combination of innovative design, efficiency and reliability makes the Flatpack S a perfect choice for telecom and industrial applications. With a system depth of only 250mm the Flatpack S systems will fit in most cabinets.
This Flatpack S reduces losses by 30% compared to the current industry standard. The result is reduced total cost of ownership for the customers as well as contribution to reducing the global carbon emissions.

Key Features

Small

Short

Power dense, 26 W/inch3

High efficiency

OR-ing protection on output

Hot pluggable

Voltage keying

Description

Compact and reliable rectifier for rail and power utilities applications

Used in the 3U rack with Smartpack S controller, the Flatpack S rectifiers cover 2 to 8kW applications using a minimum of space, less than 18 liters, and low heat dissipation.

Applications in these markets demand state of the art, reliable and safe DC power systems. Flatpack S delivers an industry leading power density in its segment, many safety functions, wide operating temperature range and superb reliability in its small 217mm deep housing.

Specifications

Input
Voltage AC (operating range)	85 - 305 VAC
Voltage DC (operating range)	85 - 300 VDC
DC Output
Max Power	1000 W
Voltage (adjustable range)	41,7 - 21,5 VDC
Current (maximum)	28 ADC
Max voltage	21,5 VDC
Other
Cooling	Single fan
Efficiency	92,5 %
Operating temperature	-40 - 85 °C
Dimensions
Dimensions WxHxD (mm)	72 x 41,5 x 217 mm
Dimensions WxHxD (inch)	2,83 x 1,63 x 8,54 "
Weight	0,85 lbs
Design Standards
Ingress Protection (IP)	20
Certifications
Marine	DNV 2.4 Valid for part no. 241122.205M
